EXKOP^® QV II

for a space-saving, bidirectional decoupling, nominal sizes up to DN 250.

Decoupling with quench valves.

The REMBE^® EXKOP^® QV II quench valve is a decoupling device that is installed in a pipeline in order to limit any explosions to the relevant part of the system. To do this, the quench valve is connected to a controller (EXKOP^® Express or EXKOP^® TriCon).

Application

REMBE^® EXKOP^® QV II is suited with a Spark arrester (e.g. between a mill and the product filter) and an overpressure limiter (e.g. between a silo vehicle and the silo).

rubber sleeve

Heating

Advantages

Compact design for flexible integration into the production process.
High level of safety due to very rapid closing times.
Returns to operation immediately after triggering.
Fail Safe mechanism automatically closes the valve if the power supply fails or the valve is manipulated.

Mechanism

In the case of an explosion, the controller receives a trigger signal (e.g. from the signalling unit of the Q-Rohr^® or an explosion vent, from a pressure switch or spark detector) and activates the connected quench valves. These close within a few milliseconds and thus prevent the explosion from spreading to adjacent plant components. After being triggered, the quench valves can be put back in operation once again at the touch of a button.

Technical data *

Product parameters

Diameter nominal**	DN 80 - DN 200	DN 250
Housing material	Aluminium, painted (RAL 1015)	St 37.2, painted (RAL 1015)
Flanges	acc. EN 1092-1 Typ 11 (PN 10)***	acc. EN 1092-1 Typ 11 (PN 10)***
Operating limits Medium	organic and chemical dusts	organic and chemical dusts
Operating limits K_St	≤ 300 bar × m/s	≤ 200 bar × m/s
Operating limits P_max	≤ 10 bar	≤ 10 bar
Operating limits MZE	≥ 3 mj	≥ 3 mj
Operating limits P_red	≤ 2,0 bar	≤ 1,0 bar
Operating limits Allowable flow rate	≤ 30 m/s	≤ 30 m/s
Operating limits ATEX category indoor/outdoor	1D/3D	1D/3D
Suitable for use in food processing industry	✓	✓
Ambient temperature	+ 5 up to + 60 °C****	+ 5 up to + 60 °C****
Installation position	any	any
Power supply	24 VDC from EXKOP^® controller	24 VDC from EXKOP^® controller
Compressed air supply	6.0 bar gauge pressure from system network	6.0 bar gauge pressure from system network
Compressed air connection	8 mm (Festo)	8 mm (Festo)
Protection type	IP 65	IP 65

* Our specialists will be pleased to assist you in finding a solution that matches your specific operating conditions.
** Other nominal diameters available on request.
*** Replaces DIN 2632, PN 10.
**** Other ambient temperature available on request.

Applications + Industries

animal feed productions
aspiration plants
brewery
chemical industry
conveyors
destoners
elevators
filters
food
food production
mills and grinding plants
mixers
pharmaceutical industry
recycling
screens
silo
spray dryers
wood processing

Certifications

ATEX EC type
examination certificate no.
FSA 04 ATEX 1537 X

Certified in
accordance with

EN 15089

Downloads

The EXKOP^® system is ideal in combination with explosion vents or flameless explosion venting solutions.
